| l1 | - | 1000 | - | t | y | t |
|---|---|---|---|---|---|---|
| Type | Length | Connection | Insert | Assembly |
| connection on both ends |
|---|
| T - Tie Plates 45 x 90 |
| P - Tie Plates 90 x 90 |
| A - 45 x 45 Angles (good on L2) |
| B - 45 x 90 Angles ( good on L2 or L3) |
| C - 90 x 90 Angles (good on L3 or L4) |
| H - Hinge for the 45mm Side (good on L2 or L3) |
| Z - No Hardware |
| Assembled or kit (assembly) |
|---|
| A - Assembled (Factory Assembles) |
| K - Kit (Customer Assembles) |
| Note |
|---|
| When using L1 inside a mesh panel as shown in the picture below please allow 4mm gap on each side. |
| Ex. - Panel Height - 98mm |
| Ex. - Panel Width - 98mm |
