Type E – Removable Panel – How to Order

Choose your options to configure your part number

E1	-	1000	-	1000	-	0150	-	g	y	m	t	a
Type		Height		Width		Sweep		Connection	Insert	Panel	Foot	Assembly

Removable Panel Type (Type)

Height

Width

Sweep

Insert

panel material (panel)

Securing System (Connection)

Foot Type (Foot)

Assembled of Kit
A - Assembled (Factory Assembly)
K - Kit (Customer Assembles)

Ready to Configure Your Guarding Section?

With our online configurator you can generate a solid model and part number for your guarding section.

Have a Custom Quote or Need Help with Your Application?

Our experienced technitions can help assist you with you needs.
